Hydraulic Motor 300ml/R 4-Bolt Magneto Flange 32mm Straight Shaft G1/2 BSPP Parker LSHT TorqmotorsTG

Shijiazhuang Hanjiu Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Hydraulic Motor 300ml/R 4-Bolt Magneto Flange 32mm Straight Shaft G1/2 BSPP Parker LSHT TorqmotorsTG

Brand Name : HANJIU

Model Number : BMER-2-300-MD-B1-R

Certification : CE, ISO9001

Place of Origin : China

MOQ : 100 Pieces

Price : 170 usd/pc

Payment Terms : T/T, Western Union

Supply Ability : 10000 pieces per year

Delivery Time : 35 - 45 work days

Packaging Details : box, pallet

Product : Low Speed High Ttoque Hydraulic Motor

Model No. : BMER-2-300-MD-B1-R

Size : 300 ml/r

Flange : 4-bolt Magneto

Shaft : 32mm

Rotation : CCW

Port : 1/2 BSP

Material : Cast iron

Contact Now

Hydraulic Motor 300ml/R 4-Bolt Magneto Flange 32mm Straight Shaft, G1/2 BSPP Parker LSHT Torqmotors

Quick review:

Model no.: BMER-2-300-MD-B1-R

matching Parker TG0280MW460AAAA

displacement 300 ml/r
flange 4-13.5 magneto mount
pilot 82.55*2.8
ports 1/2 BSP
output shaft 32mm parallel key
rotation standard
paint black

Specification:

Type BMER BMER BMER BMER BMER BMER BMER BMER BMER BMER BMER
125 160 200 230 250 300 350 375 475 540 750
Geometric displacement (cm3/rev.) 118 156 196 228 257 296 345 371 462 540 745
Max. speed (rpm) cont. 360 375 330 290 290 250 220 200 160 140 100
int. 490 470 425 365 350 315 270 240 195 170 120
Max. torque (N•m) cont. 325 450 530 625 700 810 905 990 1085 980 1050
int. 380 525 600 710 790 930 1035 1140 1180 1240 1180
peak 450 590 750 870 980 1120 1285 1360 1260 1380 1370
Max. output (kW) cont. 12.0 15.0 15.5 16.0 17.5 18.0 17.5 16.5 14.5 11.5 8.0
int. 14.0 17.5 18.0 19.0 20.0 21.0 20.0 19.0 16.5 15.0 10.0
Max. pressure drop (MPa) cont. 20.5 20.5 20.5 20.5 20.5 20.5 20.5 20.5 17.5 14 10.5
int. 24 24 24 24 24 24 24 24 19 17.5 12
peak 27.6 27.6 27.6 27.6 27.6 27.6 27.6 27.6 20.5 20.5 14
Max. flow (L/min) cont. 45 60 70 70 75 80 80 75 75 75 75
int. 60 75 85 85 90 95 95 90 90 90 90

Hydraulic Motor 300ml/R 4-Bolt Magneto Flange 32mm Straight Shaft G1/2 BSPP Parker LSHT TorqmotorsTGHydraulic Motor 300ml/R 4-Bolt Magneto Flange 32mm Straight Shaft G1/2 BSPP Parker LSHT TorqmotorsTGHydraulic Motor 300ml/R 4-Bolt Magneto Flange 32mm Straight Shaft G1/2 BSPP Parker LSHT TorqmotorsTGHydraulic Motor 300ml/R 4-Bolt Magneto Flange 32mm Straight Shaft G1/2 BSPP Parker LSHT TorqmotorsTG

The orbital hydraulic motor is a mechanical device used in many industrial equipment. It is mainly used to convert hydraulic energy into mechanical energy.

The operation of the orbital hydraulic motor is based on the principle of hydraulic force. When hydraulic fluid is pumped into the engine, it creates pressure that causes the rotor to spin. The rotor is connected to an output shaft that transfers the mechanical energy produced by the motor to the machine or equipment it powers.

This type of hydraulic motor is very efficient because it offers high starting torque and constant rotation speed. Additionally, it is capable of operating in extreme conditions, such as high temperatures or corrosive environments.

The orbital hydraulic motor also has the advantage of being compact and lightweight, which facilitates its integration into equipment and machines. Additionally, it is easy to maintain and repair, reducing maintenance costs.

In industry, orbital hydraulic motor is used in many fields such as agriculture, construction, mining and automobile. It is used to power equipment such as cranes, bulldozers, drills and agricultural machinery.

In conclusion, the orbital hydraulic motor is an essential device in many industrial sectors. With its efficiency, durability and versatility, it contributes to optimizing machine performance and increasing productivity in various applications.

HANJIU manufactures economical hydraulic motors, hydraulic directional valves and Orbitrol steering for all over the world.

We specialize in Eaton Char-lynn replacement/alternative/compatible motors
We specialize in Sauer Danfoss replacement/alternative/compatible motors
We specialize in Parker replacement/alternative/compatible motors
We specialize in Brevini replacement/alternative/compatible Motors
We are good at M+S replacement/alternative/compatible motor
